ISM-6A INDUCED SIGNAL MONITOR |
FEATURES |
Induced Current and/or Voltage options. Through use of dedicated current or voltage preamplifier units. Internal bias source with range -100V to +100V. Allows biasing of a sample to a resolution of up to 0.1mV. Large back-off current range from -20mA to +20mA. Digitally displayed with resolutions ranging from 1uA to 0.1pA |
Wide bandwidth. 3kHz bandwidth at 0.1pA resolution and 320kHz at 100nA resolution. Complete microprocessor control, with interface to PC via Labview drivers. Intuitive interface with adjustable backlight control for use in reduced ambient conditions. |
APPLICATIONS |
Characterization and observation of junction areas Failure analysis (FA) of semiconductor devices Locating areas of ESD (Electrostatic Discharge) damage |
Quality control and assurance (QA) of semiconductors Detecting subsurface damage or defects Can also be used for OBIC, EBIV, SOMSEM and CL (transmitted or emitted) studies |
OVERVIEW |
Used mainly in the EBIC mode (electron beam induced current), the ISM-6A is employed in conjunction with a scanning electron microscope to image electrically active defects in semiconductor materials and devices. Long regarded as the industry leader, the ISM series offers quantitative as well as qualitative facilities, the former enabling device parameters and materials data to be obtained. The ISM-6A builds on the original ISM-5 unit which is found in many research labs worldwide. |
